100% recycled (PCR) Plastic Cable Drums with EU Steel

All products included in this EPD are plastic & steel cable drums, 100% recycled (PCR) and EU steel. 102 variations will be included in this product group, and they all consist of 100% post-consumer recycled plastic with EU steel pipes. The material composition variation of the included product varies, with plastic content ranging from 92-98% and the steel content 8-2% (the cable drum contain four or six steel pipes). The size and dimension of the products can differ, with some cable drums having the same dimension but vary in weight. All included products share the same geographical scope and production site.

The cable drum “800 standard (dimension 800*400*83*480*400), with the article number 280064010” was chosen as representative product as it is the most sold of all the products in this product group. Since the declared unit is defined as 1 kg of cable drum (kg/kg product), the analysis was normalised to the material composition per kilogram of product. This approach means that the absolute weight of an individual drum does not affect the results; instead, the relative share of plastic and steel determines the calculated environmental impacts per kilogram. By calculating these shares, the 102 cable drum dimensions could be grouped into seven unique composition variants, ranging from approximately 92% plastic and 8% steel to 98% plastic and 2% steel. These seven compositions capture the relevant differences within the product group, where each 102 dimensions can be allocated to one of them. The representative product has a composition of 95% plastic and 5% steel.

Product code Dimension of the cable drums (mm)

310035810 Drum 1000 * 500 * 100 * 600 * 480 mm

310046010 Drum 1000 * 500 * 107 * 720 * 600 mm

310047015 Drum 1000 * 500 * 107 * 720 * 600 mm

310047010 Drum 1000 * 500 * 107 * 720 * 600 mm / Hexatronic

310355010 Drum 1000 * 500 * 107 * 740 * 600 mm

310044010 Drum 1000 * 500 * 75 * 720 * 600 mm

310030610 Drum 1000 * 500 * 80 * 520 * 400 mm

310036010 Drum 1000 * 500 * 80 * 600 * 480 mm

310036015 Drum 1000 * 500 * 80 * 600 * 480 mm

310038010 Drum 1000 * 500 * 80 * 620 * 500 mm

310041010 Drum 1000 * 500 * 80 * 680 * 560 mm

310041015 Drum 1000 * 500 * 80 * 680 * 560 mm

310042010 Drum 1000 * 500 * 80 * 680 * 560 mm

310440020 Drum 1000 * 500 * 80 * 700 * 560 mm / G10

310049010 Drum 1000 * 500 * 80 * 730 * 610 mm

310050610 Drum 1000 * 500 * 80 * 730 * 610 mm

310051010 Drum 1000 * 500 * 80 * 730 * 610 mm

310053010 Drum 1000 * 500 * 80 * 780 * 660 mm

310075010 Drum 1000 * 500 * 80 * 780 * 660 mm

310076010 Drum 1000 * 500 * 80 * 780 * 660 mm

310025010 Drum 1000 * 500 * 83 * 520 * 400 mm

310026010 Drum 1000 * 500 * 83 * 520 * 400 mm

310045010 Drum 1000 * 500 * 83 * 720 * 600 mm

310045010-15 Drum 1000 * 500 * 83 * 720 * 600 mm

310045015 Drum 1000 * 500 * 83 * 720 * 600 mm

310045020 Drum 1000 * 500 * 83 * 720 * 600 mm

310046015 Drum 1000 * 500 * 83 * 720 * 600 mm

312052020 Drum 1190 * 500 * 100 * 754 * 600 mm / TKF

312035010 Drum 1190 * 500 * 80 * 634 * 480 mm

312046020 Drum 1190 * 500 * 80 * 714 * 560 mm

312051020 Drum 1190 * 500 * 80 * 754 * 600 mm

312058025 Drum 1190 * 630 * 100 * 774 * 620 mm / TKF

312092010 Drum 1190 * 630 * 80 * 1004 * 850 mm

312093010 Drum 1190 * 630 * 80 * 1004 * 850 mm

312058010 Drum 1190 * 630 * 80 * 774 * 620 mm

312061020 Drum 1190 * 630 * 80 * 800 * 646 mm / H & S

312075020 Drum 1190 * 630 * 80 * 854 * 700 mm /

312089010 Drum 1200 * 500 * 100 * 994 * 840 mm

312090010 Drum 1200 * 500 * 100 * 994 * 840 mm / TKF

312063010 Drum 1200 * 500 * 80 * 814 * 660 mm

312095010 Drum 1200 * 630 * 107 * 1002 * 850 mm

312095015 Drum 1200 * 630 * 107 * 1002 * 850 mm

312094010 Drum 1200 * 630 * 107 * 1002 * 850 mm / Hexatronic

312059010 Drum 1200 * 630 * 107 * 774 * 620 mm / Eldra

312091010 Drum 1200 * 630 * 75 * 1002 * 850 mm

312060010 Drum 1200 * 630 * 80 * 774 * 620 mm / Opticable

312070010 Drum 1200 * 630 * 80 * 852 * 700 mm

312071010 Drum 1200 * 630 * 80 * 852 * 700 mm / OFS

312096010 Drum 1200 * 630 * 84 * 1002 * 850 mm

280395020 Drum 795 * 450 * 80 * 750 * 622 mm

280077010 Drum 800 * 375 * 75 * 580 * 500 mm

280077015 Drum 800 * 375 * 75 * 580 * 500 mm

280083010 Drum 800 * 375 * 75 * 580 * 500 mm / drainingholes

280081010 Drum 800 * 375 * 75 * 580 * 500 mm / Hexatronic

280095010 Drum 800 * 375 * 75 * 780 * 700 mm

280084010 Drum 800 * 375 * 83 * 580 * 500 mm / drainingholes

280045810 Drum 800 * 400 * 100 * 480 * 400 mm w. V-hole

280063010 Drum 800 * 400 * 75 * 480 * 400 mm

280391010 Drum 800 * 400 * 75 * 602 * 500 mm

280347010 Drum 800 * 400 * 80 * 502 * 400 mm

280071015 Drum 800 * 400 * 80 * 530 * 450 mm

280364010 Drum 800 * 400 * 80 * 552 * 450 mm

280365020 Drum 800 * 400 * 80 * 552 * 450 mm / Black

280090010 Drum 800 * 400 * 80 * 600 * 520 mm

280389010 Drum 800 * 400 * 80 * 602 * 500 mm

280390010 Drum 800 * 400 * 80 * 602 * 500 mm

280064010 Drum 800 * 400 * 83 * 480 * 400 mm (representative)

280067020 Drum 800 * 400 * 83 * 480 * 400 mm

280046810 Drum 800 * 500 * 100 * 480 * 400 mm

280079010 Drum 800 * 500 * 75 * 580 * 500 mm

280072010 Drum 800 * 500 * 80 * 540 * 460 mm

280073010 Drum 800 * 500 * 80 * 540 * 460 mm / OFS

280065010 Drum 800 * 500 * 83 * 480 * 400 mm

280062010 Drum 800 * 500 * 83 * 480 * 400 mm / drainingholes

280066010 Drum 800 * 500 * 83 * 480 * 400 mm / drainingholes

280078010 Drum 800 * 500 * 83 * 580 * 500 mm

280078015 Drum 800 * 500 * 83 * 580 * 500 mm

280078015-10 Drum 800 * 500 * 83 * 580 * 500 mm
