Light Mast

The Lightmast series is a modular lattice mast system developed to support

floodlights and related lighting equipment in demanding outdoor environments. The product is intended

for large-area outdoor lighting applications such as sports facilities, parking areas, industrial sites, port

areas, freight terminals, substations, transformer stations, traffic areas, airports, ski installations and

illuminated trails. The mast structure is manufactured in high-grade solid steel, grade S355J2, and is

hot-dip galvanized in accordance with SS-EN ISO 1461 for durable outdoor use. The design and

structural calculations are carried out in accordance with EN 1090-1.

PAGE 3/26

The mast is based on a triangular lattice construction made from modular sections in solid round steel.

The standard product system is built from prefabricated 6-metre sections that are inserted into each

other to achieve the required installation height while also reducing transport volume and simplifying

handling during installation. STRIHL’s standard stocked sections are 230x6, 340x6, 450x6, 560x6,

690x6, 890x6 and 1160x6. Smaller upper sections are combined with larger and heavier lower sections

in order to meet structural requirements as the mast height increases.
