EPD-IES-0024978:001

Medium Voltage Triple Core Power Cable

Medium voltage triple core underground power cable for electricity grid distribution systems. The lifespan of the product is considered to be 40 years under normal operating and installation conditions.

General information

EPD Owner	Hellenic Cables S.A.
Registration number	EPD-IES-0024978:001
PCR	2019:14 Construction products (EN 15804+A2) 2.0.1
c-PCR	2019:14-c-PCR-019 Electrical cables and wires (for construction sector) (c-PCR to PCR 2019:14) Adopted from EPD Norway
Status	Valid
Publication date	2025-08-13
Valid until	2030-08-07
EN 15804 compliant	Yes
Geographical scope	Global

Product images

Programme information

Programme	International EPD System
Address	EPD International AB Box 210 60 SE-100 31 Stockholm Sweden
Website	www.environdec.com
E-mail	support@environdec.com

Product category rules

CEN standard EN 15804 serves as the Core Product Category Rules (PCR)
Product Category Rules (PCR)	2019:14 Construction products (EN 15804+A2) 2.0.1
PCR review was conducted by	The Technical Committee of the International EPD System. See www.environdec.com for a list of members. Review chair: Rob Rouwette (chair), Noa Meron (co-chair). The review panel may be contacted via the Secretariat www.environdec.com/support.
Complementary Product Category Rules (c-PCR)	2019:14-c-PCR-019 Electrical cables and wires (for construction sector) (c-PCR to PCR 2019:14) Adopted from EPD Norway Version: Adopted from EPD Norway
c-PCR review was conducted by	The Technical Committee of the International EPD System

Verification

LCA accountability	nbatistatos@hellenic-cables.com, nbatistatos@hellenic-cables.com, Hellenic Cables S.A.
Independent third-party verification of the declaration and data, according to ISO 14025:2006, via	EPD verification through an individual EPD verification EPD verification through EPD Process Certification* EPD verification through a pre-verified LCA/EPD tool
Third-party verifier	Dimitris Velissariou (BQC P.C.)
Approved by	International EPD System
Procedure for follow-up of data during EPD validity involves third party verifier	Yes No
*EPD Process Certification involves an accredited certification body certifying and periodically auditing the EPD process and conducting external and independent verification of EPDs that are regularly published. More information can be found in the General Programme Instructions on www.envrondec.com.

Ownership and limitation on use of EPD

Limitations

EPDs within the same product category but published in different EPD programmes, may not be comparable. For two EPDs to be comparable, they shall be based on the same PCR (including the same first-digit version number) or be based on fully aligned PCRs or versions of PCRs; cover products with identical functions, technical performances and use (e.g. identical declared/functional units); have identical scope in terms of included life-cycle stages (unless the excluded life-cycle stage is demonstrated to be insignificant); apply identical impact assessment methods (including the same version of characterisation factors); and be valid at the time of comparison.

Ownership

The EPD Owner has the sole ownership, liability, and responsibility for the EPD.

Information about EPD Owner

EPD Owner	Hellenic Cables S.A.
Contact person name	Nikolaos Ion Batistatos
Contact person e-mail	nbatistatos@hellenic-cables.com
Organisation address	Greece Marousi 15125 Amarousiou Chalandriou 33

Description of the organisation of the EPD Owner

Hellenic Cables constitutes the cables segment of Cenergy Holdings S.A., a holding company listed on both the Euronext Brussels and the Athens Stock Exchanges. Hellenic Cables, considered as one of the leading producers of offshore and onshore cables in Europe, is globally active in the energy transmission and distribution markets in renewable energy sources (RES), telecommunications and data transmission, construction and industry sectors. The cables segment consists of Hellenic Cables S.A., the subsidiary Fulgor S.A. and Icme Ecab S.A. located in Bucharest, Romania. Hellenic Cables possesses four production facilities, three in Greece (Thiva, Eleonas and Corinth), and one in Romania (Bucharest).

Organisation logo

Product information

Product name	Medium Voltage Triple Core Power Cable FR-N20XA8E-AR (Eca,RT)-MOD 1 12/24 kV 3x240 mm2
Product identification	Medium Voltage Triple Core Power Cable FR-N20XA8E-AR (Eca,RT)-MOD 1 12/24 kV 3x240 mm2
Product description	Medium voltage triple core underground power cable for electricity grid distribution systems. The lifespan of the product is considered to be 40 years under normal operating and installation conditions.
Technical purpose of product	Hellenic Cables’ marketed product, FR-N20XA8E-AR (C2,RT)-MOD 1 3X240_Triplex 12/20 (24) kV is used in electricity transmission and distribution networks. It is a finished product which does not require further processing (apart from the installation).
Manufacturing or service provision description	The production starts with the material supply. This stage includes the mining and processing of raw materials, along with the generation of electricity and fuels required for the manufacturing. The company is part of a global supply chain, with suppliers and raw materials scattered across different continents. Main materials used in the production are the aluminium ingots used for the production of the cable conductor, aluminium-polyethylene tape, and cross-linked polyethylene (XLPE) and high density polyethylene (HDPE), used for insulation and outer sheath, respectively. Raw materials are transported to the manufacturing facility, including “intra-company” transportation. Primary materials arrive to the company’s gate mostly via trucks and container ships. Manufacturing stage includes all the processes presented below: 1. Conductor 2. Inner semiconductor 3. Insulation 4. Outer semiconductor 5. Semiconductive waterblocking tape 6. Aluminium tape 7. Outer sheath
Material properties	Linear mass density: 4.24 kg/m
Manufacturing site	Hellenic Cables Thiva manufacturing plant Greece Thiva 32200
UN CPC code	4635. Other electric conductors, for a voltage exceeding 1000 V
Geographical scope	Global
Geographical scope description	Geographical scope includes countries across the world for the procurement of raw materials. Manufacturing stage is taking place in Greece and end of life scenarios (including module D) have been modelled according to the assumption that the cable\ will be installed and used in the European region.
Actual or technical lifespan	40 year(s)

Content declaration

Hazardous and toxic substances	The product does not contain any substances from the SVHC candidate list in concentrations exceeding 0.1% of its weight.

Product content
Content name	Mass, kg	Post-consumer recycled material, mass-% of product	Biogenic material, mass-% of product	Biogenic material¹, kg C/product
Aluminium	1.85	0	0	0
Al-PE tape	0.28	0	0	0
Cross-linked polyethylene	1.25	0	0	0
Polyester	0.03	0	0	0
High density polyethylene	0.82	0	0	0
Total	4.23	0	0	0
Note 1	1 kg biogenic carbon is equivalent to 44/12 kg of CO₂

Packaging materials
Material name	Mass, kg	Mass-% (versus the product)	Biogenic material¹, kg C/product
Wooden drum	1.22	28.8	0.7
Total	1.22	28.80	0.70
Note 1	1 kg biogenic carbon is equivalent to 44/12 kg of CO₂

LCA information

EPD based on declared or functional unit	Functional unit
Functional unit description	1m of installed electrical medium voltage cable to transmit energy expressed for 1 A for 40 years and a 100% use rate
Reference flow	Cable (Medium Voltage) Length: 1 m
Conversion factor to mass	4.24
Are infrastructure or capital goods included in any upstream, core or downstream processes?	Yes No
Datasources used for this EPD	GaBi database (general) Sphera MLC (fka GaBi) Databases Edition 2025.1
LCA Software	LCA for Experts (formerly GaBi Software) N/A
Version of the EN 15804 reference package	EF Reference Package 3.1
Characterisation methods	EN 15804 EF 3.1 +A2 for all declared indicators
Technology description including background system	The production starts with the material supply. This stage includes the mining and processing of raw materials, along with the generation of electricity and fuels required for the manufacturing. The company is part of a global supply chain, with suppliers and raw materials scattered across different continents. Main materials used in the production are the aluminium ingots used for the production of the cable conductor, aluminium-polyethylene tape, and cross-linked polyethylene (XLPE) and high density polyethylene (HDPE), used for insulation and outer sheath, respectively. Primary materials arrive to the company’s gate mostly via trucks and container ships. Manufacturing stage includes all the processes presented below: 1. Conductor 2. Inner semiconductor 3. Insulation 4. Outer semiconductor 5. Semiconductive waterblocking tape 6. Aluminium tape 7. Outer sheath Primary aluminium is driven to the cast house furnaces (natural gas combustion), where the continuous casting process takes place to produce solid aluminium rod. Drawing the conductor reduces the diameter of the rod to the selected design value and then three layers of cross-linked polyethylene are simultaneously applied for insulation purposes. A polyester-based tape and an Al-PE tape are helically applied, prior to the extrusion of the outer jacket layer (high density polyethylene).
Scrap (recycled material) inputs contribution level	Less than 10% of the GWP-GHG results in modules A1-A3 come from scrap inputs

Data quality assessment

Description of data quality assessment and reference years	Site-specific data were used for the manufacturing stage. In this LCA study, specific data were used from the manufacturing facility in Thiva, Greece and Fulgor, Greece, along with supplier-specific data for aluminium. When specific data is not available, generic data from internationally recognized databases was used. FY 2024 was selected for data collection.

Data quality assessment
Process name	Source type	Source	Reference year	Data category	Share of primary data, of GWP-GHG results for A1-A3
Manufacturing of product	Collected Data	EPD Owner	2024	Primary data	2%
Generation of electricity used in manufacturing of product	Database	LCA for Experts CUP v.2025.1	2024	Primary data	3%
Transport of raw materials to manufacturing site	Database	LCA for Experts CUP v.2025.1	2024	Representative generic data	0%
Production of aluminium	EPD	Supplier EPD	2024	Primary data	55%
Production of polyethylene	Database	LCA for Experts CUP v.2025.1	2024	Representative generic data
Production of cross-linked polyethylene	Database	LCA for Experts CUP v.2025.1	2024	Representative generic data
Other processes	Databases	LCA for Experts CUP v.2025.1	2019-2024	Representative generic data
Total share of primary data, of GWP-GHG results for A1-A3					60%
The share of primary data is calculated based on GWP-GHG results. It is a simplified indicator for data quality that supports the use of more primary data to increase the representativeness of and comparability between EPDs. Note that the indicator does not capture all relevant aspects of data quality and is not comparable across product categories.

Comment on the data sources and other information in the table	All generic data used in the assessment was sourced from LCA for experts, professional database (Sphera) which is valid for 2025. The selection of the datasets was performed in a way to be more representative with regards to the geographical scope (regionalized, where possible), technology and time. When a specific dataset was missing from the database, similar datasets were chosen (as proxy).

Electricity data

Electricity used in the manufacturing process in A3 (A5 for services)
Type of electricity mix	Specific electricity mix as generated, or purchased from an electricity supplier, demonstrated by a contractual instrument
Energy sources	Hydro	14.7%
	Wind	25.2%
	Solar	17.4%
	Biomass	1.01%
	Geothermal	0%
	Waste	0%
	Nuclear	0%
	Natural gas	31.4%
	Coal	5.26%
	Oil	5.48%
	Peat	0%
	Other	0%
GWP-GHG intensity (kg CO₂ eq./kWh)	0.31 kg CO₂ eq./kWh

System boundary

Description of the system boundary	c) Cradle to grave and module D (A + B + C + D).
Excluded modules	No, there is no excluded module, or there are no excluded modules

Declared modules

	Product stage			Construction process stage		Use stage							End of life stage				Beyond product life cycle
	Raw material supply	Transport	Manufacturing	Transport to site	Construction installation	Use	Maintenance	Repair	Replacement	Refurbishment	Operational energy use	Operational water use	De-construction demolition	Transport	Waste processing	Disposal	Reuse-Recovery-Recycling-potential
Module	A1	A2	A3	A4	A5	B1	B2	B3	B4	B5	B6	B7	C1	C2	C3	C4	D
Modules declared	X	X	X	X	X	ND	ND	ND	ND	ND	X	ND	X	X	X	X	X
Geography	Europe	Greece	Greece	France	France	N/A	N/A	N/A	N/A	N/A	France	N/A	Germany	Germany	Germany	Germany	Germany
Share of specific data	60%			-	-	-	-	-	-	-	-	-	-	-	-	-	-
Variation - products	0%			-	-	-	-	-	-	-	-	-	-	-	-	-	-
Variation - sites	0%			-	-	-	-	-	-	-	-	-	-	-	-	-	-

Process flow diagram(s) related images

Default scenario

Name of the default scenario	Default scenario
Description of the default scenario	Manufacturing of Cable in Thiva, Greece. Transportation to installation site and use in France. Transportation to disposal (incineration of plastic waste and recycling of aluminium scrap). Credit for electricity, steam (thermal energy) from plastics incineration and aluminium recycling.

Module A4: Transport to the building site

Explanatory name of the default scenario in module A4	Transportation
Brief description of the default scenario in module A4	Transportation to France
Description of the default scenario in module A4	Module A4 includes road transportation of the final cable (including wooden drum for packaging) to the installation site.

Module A4 information	Value	Unit
Distance	2667	km

Module A5: Installation in the building

Explanatory name of the default scenario in module A5	Installation
Brief description of the default scenario in module A5	Only included to balance biogenic emissions.
Description of the default scenario in module A5	Module A5 is included for reporting purposes, aiming to balance out the biogenic carbon content of the packaging material (no other impacts were considered). It was assumed that the wooden drum would be reused without further treatment.

Module B6: Operational energy use

Explanatory name of the default scenario in module B6	Losses
Brief description of the default scenario in module B6	Losses from Ohm's law
Description of the default scenario in module B6	Power cables will dissipate an amount of electrical energy, expressed in watt-hours, due to the conductor’s resistivity during the operational stage. Following the principles of IEC 60228:2004, the maximum allowed resistance (20oC AC resistance) of a 240 mm2 aluminium conductor is defined to be 0,125 Ω/km. The electrical losses (P) when transmitting 1 A will be then calculated per phase as: P(Wh)= I^2RRSLLN

Module C: End-of-life

Explanatory name of the default scenario in module C	End-of-life
Brief description of the default scenario in module C	Incineration of plastic waste, recycling of aluminium
Description of the default scenario in module C	C1: Zero value as underground cables incur no environmental burden unless they are replaced. C2-C3: The used cable will be transported to the separation/recycling site and stripped for mechanical recycling of metallic components and energy recovery from its plastic components (incineration). C4: Zero value as no components are disposed of.

Reference service life

Description of the default scenario in reference service life	40 years at 100% use rate

Reference service life information	Value	Unit
Reference service life	40	year(s)
Use rate	100	%

Module D: Beyond product life cycle

Explanatory name of the default scenario in module D	Credit
Brief description of the default scenario in module D	Credit for aluminium recycling and plastics incineration
Description of the default scenario in module D	The respective exported electricity and thermal energy (EEE, EET) from plastics incineration and the replacement of aluminium ingots (primary aluminium) due to conductor recycling are recorded as credit in module D. The exact quantities for both streams (metallic parts and plastics) have been taken into consideration, according to the cable bill of materials.

Environmental performance

The estimated impact results are only relative statements, which do not indicate the endpoints of the impact categories, exceeding threshold values, safety margins and/or risks.

Mandatory environmental performance indicators according to EN 15804

Impact category	Indicator	Unit	A1-A3	A4	A5	B1	B2	B3	B4	B5	B6	B7	C1	C2	C3	C4	D
Climate change - total	GWP-total	kg CO₂ eq.	1.77E+1	1.50E+0	2.08E+0	ND	ND	ND	ND	ND	1.00E-2	ND	0.00E+0	9.32E-2	5.67E+0	0.00E+0	-8.36E-3
Climate change - fossil	GWP-fossil	kg CO₂ eq.	1.97E+1	1.52E+0	0.00E+0	ND	ND	ND	ND	ND	9.86E-3	ND	0.00E+0	9.43E-2	5.67E+0	0.00E+0	-1.04E+1
Climate change - biogenic	GWP-biogenic	kg CO₂ eq.	-2.05E+0	-3.38E-2	2.08E+0	ND	ND	ND	ND	ND	1.23E-4	ND	0.00E+0	-2.10E-3	1.86E-3	0.00E+0	2.10E+0
Climate change - land use and land-use change	GWP-luluc	kg CO₂ eq.	3.56E-2	1.57E-2	0.00E+0	ND	ND	ND	ND	ND	3.00E-5	ND	0.00E+0	9.76E-4	4.71E-4	0.00E+0	-6.47E-3
Ozone depletion	ODP	kg CFC-11 eq.	9.92E-11	2.53E-13	0.00E+0	ND	ND	ND	ND	ND	5.07E-13	ND	0.00E+0	1.57E-14	3.48E-12	0.00E+0	-3.57E-11
Acidification	AP	mol H⁺ eq.	1.47E-1	1.08E-2	0.00E+0	ND	ND	ND	ND	ND	2.67E-5	ND	0.00E+0	6.71E-4	9.81E-4	0.00E+0	-9.70E-2
Eutrophication aquatic freshwater	EP-freshwater	kg P eq.	5.17E-5	4.11E-6	0.00E+0	ND	ND	ND	ND	ND	3.58E-8	ND	0.00E+0	2.56E-7	4.29E-7	0.00E+0	-1.28E-5
Eutrophication aquatic marine	EP-marine	kg N eq.	1.90E-2	5.41E-3	0.00E+0	ND	ND	ND	ND	ND	8.09E-6	ND	0.00E+0	3.36E-4	3.03E-4	0.00E+0	-9.19E-3
Eutrophication terrestrial	EP-terrestrial	mol N eq.	2.06E-1	5.88E-2	0.00E+0	ND	ND	ND	ND	ND	8.44E-5	ND	0.00E+0	3.65E-3	4.41E-3	0.00E+0	-1.01E-1
Photochemical ozone formation	POCP	kg NMVOC eq.	6.13E-2	1.02E-2	0.00E+0	ND	ND	ND	ND	ND	1.87E-5	ND	0.00E+0	6.37E-4	8.44E-4	0.00E+0	-2.97E-2
Depletion of abiotic resources - minerals and metals	ADP-minerals&metals¹	kg Sb eq.	2.31E-6	1.01E-7	0.00E+0	ND	ND	ND	ND	ND	4.43E-9	ND	0.00E+0	6.31E-9	3.68E-8	0.00E+0	-1.16E-6
Depletion of abiotic resources - fossil fuels	ADP-fossil¹	MJ, net calorific value	3.29E+2	1.95E+1	0.00E+0	ND	ND	ND	ND	ND	1.02E+0	ND	0.00E+0	1.22E+0	7.77E+0	0.00E+0	-1.16E+2
Water use	WDP¹	m³ world eq. deprived	4.55E+0	6.97E-3	0.00E+0	ND	ND	ND	ND	ND	3.92E-3	ND	0.00E+0	4.34E-4	5.07E-1	0.00E+0	-1.96E+0
Acronyms	GWP-fossil = Global Warming Potential fossil fuels; GWP-biogenic = Global Warming Potential biogenic; GWP-luluc = Global Warming Potential land use and land use change; ODP = Depletion potential of the stratospheric ozone layer; AP = Acidification potential, Accumulated Exceedance; EP-freshwater = Eutrophication potential, fraction of nutrients reaching freshwater end compartment; EP-marine = Eutrophication potential, fraction of nutrients reaching marine end compartment; EP-terrestrial = Eutrophication potential, Accumulated Exceedance; POCP = Formation potential of tropospheric ozone; ADP-minerals&metals = Abiotic depletion potential for non-fossil resources; ADP-fossil = Abiotic depletion for fossil resources potential; WDP = Water (user) deprivation potential, deprivation-weighted water consumption
General disclaimer	The results of the end-of-life stage (modules C1-C4) should be considered when using the results of the product stage (modules A1-A3/A1-A5 for services).
Disclaimer 1	The results of this environmental impact indicator shall be used with care as the uncertainties of these results are high or as there is limited experience with the indicator

Additional mandatory environmental performance indicators

Impact category	Indicator	Unit	A1-A3	A4	A5	B1	B2	B3	B4	B5	B6	B7	C1	C2	C3	C4	D
Climate change - GWP-GHG	GWP-GHG¹	kg CO₂ eq.	1.76E+1	1.50E+0	2.08E+0	ND	ND	ND	ND	ND	9.89E-3	ND	0.00E+0	9.40E-2	5.67E+0	0.00E+0	-8.34E+0
Acronyms	GWP-GHG = Global warming potential greenhouse gas.
General disclaimer	The results of the end-of-life stage (modules C1-C4) should be considered when using the results of the product stage (modules A1-A3/A1-A5 for services).
Disclaimer 1	The GWP-GHG indicator is termed GWP-IOBC/GHG in the ILCD+EPD+ data format. The indicator accounts for all greenhouse gases except biogenic carbon dioxide uptake and emissions and biogenic carbon stored in the product. As such, the indicator is identical to GWP-total except that the CF for biogenic CO₂ is set to zero.

Resource use indicators according to EN 15804

Indicator	Unit	A1-A3	A4	A5	B1	B2	B3	B4	B5	B6	B7	C1	C2	C3	C4	D
PERE	MJ, net calorific value	3.63E+2	1.47E+0	0.00E+0	ND	ND	ND	ND	ND	3.00E-1	ND	0.00E+0	9.16E-2	1.61E+0	0.00E+0	-2.75E+2
PERM	MJ, net calorific value	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	0.00E+0	0.00E+0	0.00E+0
PERT	MJ, net calorific value	2.22E+0	1.47E+0	0.00E+0	ND	ND	ND	ND	ND	3.00E-1	ND	0.00E+0	9.16E-2	1.61E+0	0.00E+0	-1.60E+2
PENRE	MJ, net calorific value	2.36E+2	1.95E+1	0.00E+0	ND	ND	ND	ND	ND	1.02E+0	ND	0.00E+0	1.22E+0	7.77E+0	0.00E+0	-2.02E+2
PENRM	MJ, net calorific value	9.33E+1	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	0.00E+0	0.00E+0	0.00E+0
PENRT	MJ, net calorific value	3.29E+2	1.95E+1	0.00E+0	ND	ND	ND	ND	ND	1.02E+0	ND	0.00E+0	1.22E+0	7.77E+0	0.00E+0	-1.16E+2
SM	kg	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	0.00E+0	0.00E+0	0.00E+0
RSF	MJ, net calorific value	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	0.00E+0	0.00E+0	0.00E+0
NRSF	MJ, net calorific value	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	0.00E+0	0.00E+0	0.00E+0
FW	m³	4.17E-1	7.28E-4	0.00E+0	ND	ND	ND	ND	ND	4.40E-4	ND	0.00E+0	4.53E-5	1.24E-2	0.00E+0	-2.83E-1
Acronyms	PERE = Use of renewable primary energy excluding renewable primary energy resources used as raw materials; PERM = Use of renewable primary energy resources used as raw materials; PERT = Total use of renewable primary energy resources; PENRE = Use of non-renewable primary energy excluding non-renewable primary energy resources used as raw materials; PENRM = Use of non-renewable primary energy resources used as raw materials; PENRT = Total use of non-renewable primary energy re-sources; SM = Use of secondary material; RSF = Use of renewable secondary fuels; NRSF = Use of non-renewable secondary fuels; FW = Use of net fresh water.
General disclaimer	The results of the end-of-life stage (modules C1-C4) should be considered when using the results of the product stage (modules A1-A3/A1-A5 for services).

Waste indicators according to EN 15804

Indicator	Unit	A1-A3	A4	A5	B1	B2	B3	B4	B5	B6	B7	C1	C2	C3	C4	D
HWD	kg	9.20E-8	7.84E-10	0.00E+0	ND	ND	ND	ND	ND	5.46E-10	ND	0.00E+0	4.88E-11	3.47E-9	0.00E+0	-3.72E-8
NHWD	kg	4.76E+0	2.73E-3	0.00E+0	ND	ND	ND	ND	ND	3.28E-4	ND	0.00E+0	1.70E-4	4.85E-1	0.00E+0	-3.03E+0
RWD	kg	4.16E-3	3.69E-5	0.00E+0	ND	ND	ND	ND	ND	3.19E-4	ND	0.00E+0	2.29E-6	1.83E-4	0.00E+0	-2.78E-3
Acronyms	HWD = Hazardous waste disposed; NHWD = Non-hazardous waste disposed; RWD = Radioactive waste disposed.
General disclaimer	The results of the end-of-life stage (modules C1-C4) should be considered when using the results of the product stage (modules A1-A3/A1-A5 for services).

Output flow indicators according to EN 15804

Indicator	Unit	A1-A3	A4	A5	B1	B2	B3	B4	B5	B6	B7	C1	C2	C3	C4	D
CRU	kg	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	0.00E+0	0.00E+0	1.22E+0
MFR	kg	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	2.11E+0	0.00E+0	0.00E+0
MER	kg	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	2.13E+0	0.00E+0	0.00E+0
EEE	MJ, net calorific value	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	0.00E+0	0.00E+0	9.65E+0
EET	MJ, net calorific value	0.00E+0	0.00E+0	0.00E+0	ND	ND	ND	ND	ND	0.00E+0	ND	0.00E+0	0.00E+0	0.00E+0	0.00E+0	1.73E+1
Acronyms	CRU = Components for re-use; MFR = Materials for recycling; MER = Materials for energy recovery; EEE = Exported electrical energy; EET = Exported thermal energy.
General disclaimer	The results of the end-of-life stage (modules C1-C4) should be considered when using the results of the product stage (modules A1-A3/A1-A5 for services).

References

a) General Programme Instructions of the International EPD® System. Version 5.0

b) PCR 2019:14 v.2.0.1 Construction products EPD System

c) EN 15804:2012+A2:2019 Sustainability of construction works - Environmental Product Declarations, Core rules for the product category of construction products

d) ISO 14020:2000 Environmental labels and declarations, General principles

e) ISO 14025:2006 Environmental labels and declarations - Type III environmental declarations — Principles and procedures

f) ISO 14040:2006 Environmental management - Life cycle assessment-Principles and framework

g) ISO 14044:2006 Environmental management - Life cycle assessment - Requirements and guidelines

h) PCR 2019:14-c-PCR-019 Electrical cables and wires

Version history

Original Version of the EPD, 2025-08-08
