Fencing mesh: Knotted & Chain link

The fencing mesh type knotted and chain link is use in the agricultural, residential and professional sectors. It is suitable as fencing for public infrastructures such as motorways and roads, railways and high-speed trains, airports, etc.

1 - Knotted fences: manufacturing with low or high carbon content.

1a - XK fence

Wires diameter (mm): Verticals: 2.00 → 2.50. Horizontals: 2.00 → 3.43

Distance between vertical wires (cm): 5 / 7.5 / 10 / 15 / 22 / 30

Type : Progressive or non progressive (non-climb)

Height: 0.60m → 2.60m

Roll length: up to 500m

Option of Zinc or ZnAl® galvanization according to standards: EN 10244-2; ASTM A641; ASTM A6856

Option : Integration of a hinge knot line in XK meshes.

1b - FK fence

Wires diameter (mm): Verticals: 2.00 → 2.50. Horizontals: 2.00 → 3.50

Distance between vertical wires (cm): 7.5 / 15 / 22 / 30/ 45

Type : Progressive or non progressive (non-climb)

Height: 0.60m → 3.05m

Roll length: up to 200m

Option of Zinc or ZnAl® galvanization according to standards: EN 10244-2; ASTM A641; ASTM A6856

Options: Ecover® or Ecoblack coating for some or all wires. Provides up to three times the corrosion resistance of Class A reinforced galvanized wire -

1c - HJ fence

Wires diameter (mm): Verticals: 1.60 → 3.00. Horizontals: 1.60 → 4.00

Distance between vertical wires (cm): 15 / 30

Type : Progressive

Height: 0.50m → 2.20m

Roll length: up to 300m

Option of Zinc or ZnAl® galvanization according to standards: EN 10244-2; ASTM A641; ASTM A6856

2 - Chain link fence: manufacturing with low carbon content.

Wires diameter (mm): Galvanized: 1.80mm → 3.90mm – PVC coated: 2.70mm →4.40mm

Mesh sizes: 30mm → 60mm

Height: 0.50m → 4.00m

Roll length: up to 300m

Option of Zinc or ZnAl® galvanization according to standards: EN 10244-2; ASTM A641; ASTM A6856

Options: Roll: compacted or non compacted. Ends: barbed (protruding) or knuckled (turned over).
