Revolution 100 Partition System
Product information
Revolution 100 is a stunning dry-jointed system allowing to maintain the same visual appearance across a workspace, whilst addressing varying acoustic requirements.
This versatile system can incorporate a number of extruded aluminium deflection heads. Both inner and outer deflection heads are available, to suit your design intent, and can accommodate up to +/-25mm or +/-40mm deflection. If there is no deflection, a simple 25mm or 50mm extruded aluminium head channel is all that is required. The aluminium base channel can either be 25mm or 50mm deep, depending upon your desired aesthetic.
Revolution 100 is also available in single-glazed form, with the glazing offset, with discreet glass-to-glass joints between the glazed panels. Revolution 100 single glazing can accommodate glass panels up to 1500mm wide, subject to height, configuration, and site logistics.
Another version, Revolution 100 Shoreditch Edition, features a slimline aluminium framework. Bonded to the glass it retains the structural stability and acoustic performance of the glass partition, whilst giving the appearance of cutting through the glass.
The aluminium framework of all Optima Products’ partition systems can be supplied in either powder coated or anodised finish.
Partitions are customisable, and indeed normally customised, to suit the context in which they are installed.
Detailed information
EPD Owner
EPD documents
EPD_Revolution100.pdfOther documents
Included products in this EPD
Revolution 100 Partitioning
